Load & Performance Testing

Performance & Load Testing your web services is crucial with APIs becoming more prevalent in usage and required through testing for handling adhoc and busrt loads thoughout the product lifecycle. K6.io is one such tool from well known opensource team graphna labs that enables basic to advance testing sceraios for the developers to test their API's and identify any potential blockages across the service by writing tests in their well known scripting language 'javascript'. This blog article guides you to quickly setup and run the load test in literaly in 5 minutes. YES in 5, can't beleive jump write in

Features :

available as opensource and also SaaS
Script tests in Javascript
Supports 3rd party integrations and extensions
quick to setup and use

Lets Begin...

Install k6

for mac os with homebrew package manager
```
brew install k6
```

for linux or debian follow these steps

sudo gpg --no-default-keyring --keyring /usr/share/keyrings/k6-archive-keyring.gpg --keyserver hkp://keyserver.ubuntu.com:80 --recv-keys C5AD17C747E3415A3642D57D77C6C491D6AC1D69
echo "deb [signed-by=/usr/share/keyrings/k6-archive-keyring.gpg] https://dl.k6.io/deb stable main" | sudo tee /etc/apt/sources.list.d/k6.list
sudo apt-get update
sudo apt-get install k6

refer k6 documentation for additional options k6

Get started with test scripts To perform testing on your web application & apis; create new script file for example script.js and use below sample code

   import http from 'k6/http';
   import { sleep } from 'k6';

   export default function () {
   http.get('https://test.k6.io');
   sleep(1);
   }

If you are feeling to do more use below script

import {check} from 'k6';
import http from 'k6/http';

const URL = 'https://dummyjson.com/products/1'
// const SEARCH_URL = 'https://dummyjson.com/products/search?q=phone'


var params = {
   Headers: {
       'Content-Type': 'application/json',
       // 'Authorization':'Bearer your key or bearer tokens for the api endpoint'
   },
};

// Simple Get request for 5 concuerrent in 3 s

export let options = {
   vus: 5,
   duration: '30s'
}


export default function () {
   let res = http.get(URL, params);
   // console.log(res)
   check(res, {
       'is status 200': (r) => r.status ===200
   });
}

Run the tests - use the command k6 run script.js where script.js is the file name in step 2 above. script file can be named anything, as a best practice name it base don on waht script is expected to do
By default it uses 1 virtual user, for running multiple users or simultaneous users use k6 run --vus 5 --duration 30s script.js this refers to 5 virtual users for the duration of 30 seconds. Add or change numbers based on what you are trying to acheive. Also can be added to the script under options object. Additional options are available, refer to K6 documentation
Results are displayed upon compeletion with required metrices for users broadly classifed into 2
- As summary statistics, in an end-of-test summary report.
- In granular details, with measurements for every data point across test (and timestamps)

Sample Result for 5 VUS and 30s Duration from k6/script_get.js in github repository mentioned below

k6 run script_get.js

        /\      |‾‾| /‾‾/   /‾‾/
    /\  /  \     |  |/  /   /  /
    /  \/    \    |     (   /   ‾‾\
/          \   |  |\  \ |  (‾)  |
/ __________ \  |__| \__\ \_____/ .io

execution: local
    script: script_get.js
    output: -

scenarios: (100.00%) 1 scenario, 5 max VUs, 1m0s max duration (incl. graceful stop):
        * default: 5 looping VUs for 30s (gracefulStop: 30s)

    ✓ is status 200

    checks.........................: 100.00% ✓ 2732      ✗ 0
    data_received..................: 1.8 MB  59 kB/s
    data_sent......................: 101 kB  3.4 kB/s
    http_req_blocked...............: avg=435.17µs min=0s      med=1µs     max=243.67ms p(90)=1µs     p(95)=2µs
    http_req_connecting............: avg=49.01µs  min=0s      med=0s      max=28.26ms  p(90)=0s      p(95)=0s
    http_req_duration..............: avg=54.23ms  min=31.52ms med=50.78ms max=720.83ms p(90)=64.94ms p(95)=73.46ms
    { expected_response:true }...: avg=54.23ms  min=31.52ms med=50.78ms max=720.83ms p(90)=64.94ms p(95)=73.46ms
    http_req_failed................: 0.00%   ✓ 0         ✗ 2732
    http_req_receiving.............: avg=918.92µs min=25µs    med=103µs   max=77.08ms  p(90)=1.98ms  p(95)=3ms
    http_req_sending...............: avg=126.7µs  min=21µs    med=96µs    max=13.78ms  p(90)=205µs   p(95)=279.89µs
    http_req_tls_handshaking.......: avg=170.46µs min=0s      med=0s      max=100.87ms p(90)=0s      p(95)=0s
    http_req_waiting...............: avg=53.19ms  min=31.31ms med=49.86ms max=720.59ms p(90)=64.07ms p(95)=71.94ms
    http_reqs......................: 2732    90.903468/s
    iteration_duration.............: avg=54.89ms  min=31.67ms med=50.99ms max=721.07ms p(90)=65.28ms p(95)=74.14ms
    iterations.....................: 2732    90.903468/s
    vus............................: 5       min=5       max=5
    vus_max........................: 5       min=5       max=5


running (0m30.1s), 0/5 VUs, 2732 complete and 0 interrupted iterations
default ✓ [======================================] 5 VUs  30s
```

As you can see with 10 to 20 lines of code we were able to run 2700++ requests with 5 virtual users with max duration of 30s. Go ahead and try it out yourself.

There are some samples for http methods like get, put, post and one may refer to code in k6 folder of the github repository. I have used dummyjson.com for api requests and response assertions and request url's may be updated to suit your needs before executing the scripts. Feel free to modify and use it as needed.
